ISO 7010 E068 Lifebuoy With Light and Smoke Sign – CAD Block, PDF & SVG
The ISO 7010 E068 Lifebuoy With Light and Smoke Sign CAD Block identifies the position of lifebuoys equipped with both light and smoke signals. It directs crew members, port staff, and passengers toward enhanced man-overboard rescue equipment that improves visibility during day and night. As a result, you support faster reaction times, clearer localization of casualties in the water, and more effective emergency response in marine and waterfront environments.
Because the design follows ISO 7010 E068, the symbol is easily understood on ships, offshore platforms, ferry terminals, marinas, and port facilities. The same graphic appears on safety plans, bridge and deck diagrams, quay walls, and railings near lifebuoy brackets. Therefore, when you add this CAD block to your drawings, users immediately recognize that the marked location provides a lifebuoy complete with light and smoke signals. In turn, your layouts remain aligned with international best practice for man-overboard (MOB) safety and marine emergency communication.
This safe condition sign CAD block comes in DWG, PDF, and SVG formats. You can insert the DWG file directly into AutoCAD, BricsCAD, or DraftSight for ship, terminal, and waterfront drawings. Additionally, you can send the PDF to print shops or use the SVG in Illustrator, Inkscape, CNC workflows, and digital signage systems. The vector-based geometry maintains sharp symbol detail at every scale, from small onboard labels to large dockside and terminal panels. For complete safe condition signage coverage across a project, refer to the ISO 7010 Safe Condition Signs – Full CAD Block Set (DWG, PDF & SVG).
Key Features
- Accurate CAD drawing of ISO 7010 E068 Lifebuoy With Light and Smoke Sign
- Supplied in DWG, PDF, and SVG formats for flexible marine-safety workflows
- Ready for AutoCAD, BricsCAD, DraftSight, CNC tools, and graphics software
- Uses ISO 3864-1 safe condition color standard (Green RAL 6032 / HEX #00A650)
- Ideal for ships, ferries, offshore units, marinas, ports, and waterfront promenades
Applications
- Mark lifebuoy-with-light-and-smoke stations in general arrangement plans, deck layouts, and terminal diagrams
- Insert the symbol into CAD-based safety plans, man-overboard response charts, and signage schedules
- Use it in crew training booklets, passenger safety information, and port authority guidance documents
- Coordinate with SOLAS, flag-state rules, port regulations, and internal emergency procedures
- Explore more safe condition symbols in our Safe Condition Signs CAD blocks collection
Compliance
This CAD symbol follows ISO 7010 E068 and ISO 3864-1 requirements for safe condition signage related to lifebuoys with light and smoke. Consequently, your drawings use the same visual language expected by safety officers, marine surveyors, and port-state inspectors. Moreover, clear and consistent marking of enhanced lifebuoy stations improves wayfinding during drills and real incidents, because crew and bystanders can quickly locate the correct equipment to mark a casualty’s position in the water.
For a wider range of compliant graphics, you can browse the full AppisCAD safety sign CAD block collection. To learn more about how ISO 7010 defines international safety symbols, visit ISO 7010:2019 (Registered safety signs).
