Wear Personal Flotation Devices Sign CAD Block
The Wear Personal Flotation Devices Sign CAD Block (ISO 7010 M053) is a mandatory safety symbol for marinas, docks, boat ramps, rafting bases, and water-sport training centers. It instructs staff, visitors, and students to wear approved life jackets or personal flotation devices (PFDs) whenever they operate on or near the water. By following this rule, teams reduce drowning risk, speed up safety checks, and create a culture of prevention.
Water conditions change quickly; wind, waves, and cold shock turn minor slips into serious incidents. Therefore, supervisors need signage that people understand at a glance. This ISO-compliant symbol provides that clarity. It reminds users to put on a PFD before boarding a vessel, launching a kayak, or stepping onto a floating pier. Moreover, the message remains consistent across languages and locations, so seasonal staff and international guests grasp the requirement immediately.
This Mandatory sign CAD block uses a blue circular background with a white life-jacket pictogram. The blue field indicates a required action, while the simple icon delivers instant recognition. Furthermore, the proportions and color values follow ISO guidance, which helps you standardize
safety sheets, marina drawings, and operating procedures with confidence.
The CAD block works seamlessly with AutoCAD and other leading drafting platforms. You receive scalable vector files that preserve crisp geometry at every size. The package includes .dwg, .pdf, and .svg formats for digital drawings, print output, and signage fabrication. Standard sizes range from 200 mm to 400 mm; however, larger signs improve visibility on busy piers or windy shorelines. In addition, the clean layout fits perfectly into evacuation maps, equipment boards, and staff training packs.
Key Features
- Accurate CAD drawing of ISO 7010 M053 “Wear Personal Flotation Devices” symbol
- Follows ISO 3864-1 for color, layout, and proportion
- Compatible with AutoCAD and other major CAD platforms
- Provided in .dwg, .pdf, and .svg for flexible integration
- Ideal for marinas, docks, boat ramps, rafting and kayak bases, and training centers
Applications
Place this symbol wherever people must wear a PFD before entering watercraft or approaching the edge of a pier. Typical locations include boat rental counters, life-jacket stations, dock gates, launch ramps, sailing classrooms, and lifeguard briefings. By adding this CAD block to your plans, you improve compliance, streamline staff instructions, and reduce incident rates. Consequently, operations run smoother and audits become easier. For related designs, explore our full range of Safety sign CAD blocks. and download the ISO 7010 Mandatory Signs Full CAD Block Set to access the complete library in DWG, PDF, and SVG formats
Compliance
This CAD block complies with ISO 7010 (M053) and ISO 3864-1 requirements for mandatory safety signage. Therefore, it supports consistent safety communication on docks, boats, and waterfront facilities. To complete your set, view our collection of ISO 7010 safety signs or learn more about how ISO 7010 defines international safety symbols, visit ISO 7010:2019 (Registered safety signs).
