Ventilate Before and During Entering Sign CAD Block
The Ventilate Before and During Entering Sign CAD Block (ISO 7010 M056) is a mandatory safety symbol used in confined spaces, chemical storage rooms, sewer access points, and other oxygen-deficient or gas-prone environments. It instructs personnel to ventilate the area both before and during entry. This helps disperse harmful gases, increase oxygen levels, and prevent serious health risks such as asphyxiation, dizziness, or unconsciousness. The symbol delivers a universal message that supports hazard awareness and safe workplace entry procedures, especially in high-risk maintenance and inspection areas.
This Mandatory sign CAD block features a blue circular background with a white pictogram of a person entering a space with active ventilation. The color blue signals a required safety action, while the simplified icon allows rapid understanding across diverse languages and teams. The CAD drawing integrates seamlessly with AutoCAD and all major CAD software. Supplied in scalable vector formats—.dwg, .pdf, and .svg—it retains line clarity across all signage sizes from 200 mm to 400 mm, making it ideal for use on access doors, mechanical control boards, or safety briefing areas.
Key Features
- Precise CAD representation of ISO 7010 M056 “Ventilate Before and During Entering”
- Follows ISO 3864-1 standards for color, proportion, and layout
- Compatible with AutoCAD, BricsCAD, DraftSight, and other platforms
- Provided in .dwg, .pdf, and .svg for flexible deployment in plans and signage
- Ideal for confined spaces, utility vaults, sewer systems, maintenance tunnels, and chemical handling areas
Applications
- Install on or near access hatches, confined space entries, tank rooms, and vent control panels
- Supports entry-permit systems and safety briefings
- Helps reduce accident rates and increase inspection compliance
- Explore more designs in our Safety sign CAD blocks collection
- Download the ISO 7010 Mandatory Signs Full CAD Block Set to access the complete library in DWG, PDF, and SVG formats
Compliance
Complies with ISO 7010 (M056) and ISO 3864-1 for international safety signage standards. Maintain consistent workplace safety communication by exploring our full range of ISO 7010 safety signs or learn more about how ISO 7010 defines international safety symbols, visit ISO 7010:2019 (Registered safety signs).
| Version | 2.1 |
|---|
